400x400mm Recommended Platform Size Stainless Steel Load Cell C3 100kg 200kg 300kg 500kg for Industrial Weight Control

Ask Lasest Price
Model Number :	6G
Brand Name :	SNC
Price :	$135/pieces 4-39 pieces

Add to Cart

Product Details
Company Profile

400x400mm Recommended Platform Size Stainless Steel Load Cell C3 100kg 200kg 300kg 500kg for Industrial Weight Control

stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor

Features:

Single point with parallel beam.
17-4PH stainless steel, hermetically welded, oil-proof, waterproof and anti-corrosion, Suitable for all kinds of environments.
Suitable for platform scales, electronic scales, belt scales and other electronic weighing devices.
Capacity:10kg to 500kg.
Recommended platform size: 400x400mm(10kg-100kgSE) / 800x800mm(75kg-500kg)

50 KG 100 KG 200 KG 500KG waterproof stainless steel load cell

Diameters: mm

stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor

Parameters:

Capacity	kg	10/20/50/75/100/150/200/300/400/500
Accuracy class		C3	C4	C5
Maximum number	n max	$3,000	$4,000	$5,000
of verification intervals
Minimum load cell	v min	Emax/10000	Emax/15000	Emax/20000
verification interval
Combined error	(%FS)	≤±0.0230	≤±0.0173	≤±0.0140
Creep	(%FS/30min)	≤±0.0245	≤±0.0184	≤±0.0147
Temperature effect	(%FS/10℃)	≤±0.0117	≤±0.0088	≤±0.0070
on sensitivity
Temperature	(%FS/10℃)	≤±0.0140	≤±0.0093	≤±0.0070
effect on zero
Output sensitivity	(mv/v)	2.0±0.2
Input resistance	(Ω)	10kg-50kgSE/75kgSE/100kgSE		75/100/150/-500kg
		380±15		350±3.5
Output resistance	(Ω)	350±3.5
Insulation resistance	(MΩ)	≥5000(50VDC)
Zero balance	(%FS)	≤±2.0%
Temperature,	(℃)	-10~+40
compensated
Temperature, operating	(℃)	-35~+70
Excitation,	(V)	5~12(DC)
Recommended
Excitation, Max	(V)	18(DC)
Safe overload	(%FS)	$150
Ultimate overload	(%FS)	$300
Protection Class		IP68/IP69K

Company Information

Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor

Packaging & Shipping

stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor

Our Services

stainless steel load cell 6G C3 100kg 200kg 300kg 500kg stainless steel weight sensor

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
