Non-Contact Torque Sensor ZHKY8050DS 0.1nm 0.5nm 1nm 2nm 5nm for Accurate Torque Readings in Industrial Applications

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

Product Description

Features:

Model: ZHKY8050DS

Torque capacity range: 0~0.2/0.3/0.5/1/2/3/5 N.m

Material: Alloy steel

Speed measure: YES, max. 4000 RPM (If NO need speed measure, please refer to ZHKY8050D )

Accessory included: Torque sensor cable.

Optional accessory: Torque meter, speed meter, coupling, English software

Parameters:

Model	ZHKY8050DS
Capacity	0~0.2/0.3/0.5/1/2/3/5
Output sensitivity	1.0~2.0mv/v
Speed measure	YES, max. 4000 RPM
Linearity	±0.1; ±0.3
Hysteresis	±0.1; ±0.3
Repeatability	±0.1; ±0.3
Working Temperature:	-10~+60 ℃
Temperature compensated range:	room temperature +60 ℃
Temperature effect on zero:	±0.1 %F.S/10 ℃
Excitation voltage :	12 VDC
Insulted resistance:	2000 MΩ/100VDC
Input resistance:	350±10 Ω
Output resistance:	350±5 Ω
Zero output:	0~±1 %F.S
Safety overload:	120 %F.S
Cable length:	3 m
Cable connection:	Red: output (signal+) Yellow: Output (signal-) White: Input (Excitation-) Green: Input (Excitation+)

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

Accessories

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

Product Uses

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

Company Information

Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

Packaging & Shipping

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.

ZHKY8050DS Dynamic shaft type micro rotary torque speed sensor 0.1nm 0.5nm 1nm 2nm 5nm
